Microbulk tanks in kuwait - Victank
Microbulk Tank Horizontal MBH5000VHP
Inquire

The products are easy to use and are perfect for a variety of applications. We welcome an prospect to do enterprise along with you and hope to have pleasure in attaching even more aspects of our items.

Description

Microbulk enable small and medium volume users to enjoy the benefits of on-site gas delivery. MicroBulk Storage Systems provide reliable, efficient and economical solutions for liquid nitrogen, oxygen, argon, CO2, N2O, and LNG.

Designed to replace high pressure gas cylinders, VICTANK eliminates:

•      waste and expense of full for empty gas cylinders

•      cylinder change-overs

•      residual gas losses

•      lost or damaged cylinders

•      cylinder inventory management

•      manual handling injuries



Horizontal microbulk tank is suitable for general container loading and also for where the installation space limited by the height.


microbulk tank, liquid oxygen tank, lox tank, cryogenic tank, Liquid nitrogen tank, LIN, LAR, LCO2, LNG, liquid argon, liquid gas tank, medical

Technical Datasheet

ASME standard 5000L-35bar

MBH5000VHP

MAWP

Mpa(psi)

3.5(500)

Max. Pre-set Operating Press

Mpa(psi)

3.1(450)

Gross Volume

L(gal)

5031(1329)

Net Volume

L(gal)

4629(1223)

NER(Nitrogen)

%/Day

0.6

Gaseous Volume(Oxygen)

Nmˆ3(SCF)

3695(130502)

Gaseous Volume(Nitrogen)

Nmˆ3(SCF)

2976(105101)

Gaseous Volume(Argon)

Nmˆ3(SCF)

3615(127658)

Gas delivery rate

Nmˆ3/H(SCFH)

100(3532)

Pallet Width "A"

mm(inch)

3150(124.01)

Pallet Length "B"

mm(inch)

1400(55.12)

Tank Diameter "D"

mm(inch)

1910(75.2)

Overall Height "H"

mm(inch)

2150(84.64)

Width w/piping "w"

mm(inch)

2230(87.8)

Material:

Inner vessel: stainless steel

Outer vessel: stainless steel


Reports & Certificate

Victank microbulk tanks meet the most stringent international standard. With strict management and test procedure, Victank microbulk tanks enjoy high performance and reliable quality.

Full sets of test report are provided along with microbulk tanks.

Third party test reports are available upon request.

More details about reports and certificates, just contact Victank.

Warranty

Victank Microbulk tanks always maintain a qualified vacuum and heat preservation performance. We give warranty of 7 years, which is the best and only in the world!

Free training on installation, operation and maintenance.

Life-long technical assistance online.


Packaging & Shipping


1units shipped by 1x20GP container.

3units shipped by 1x40GP container.


We are sincerely looking for establishing a long-term business relationship with customers all circles, with mutual benefits and become one of the most reliable Chinese supplier for customers all over the world. Microbulk tanks in kuwait - Victank, The product will supply to all over the world, such as: Manila, Hamburg, Somalia, Bangkok, Excellent quality, competitive price, punctual delivery and dependable service can be guaranteed. For further inquires please do not hesitate to contact us. Thank you - Your support continuously inspires us.
