Gaining purchaser gratification is our company's aim eternally. We're going to make great initiatives to create new and top-quality products, satisfy your exclusive prerequisites and supply you with pre-sale, on-sale and after-sale solutions for We cordially welcome shoppers from in the home and overseas to hitch us and cooperate with us to enjoy a better future.
MicroBulk is a cost-effective gas management solution that provides the efficiencies of bulk delivery to smaller volume users of nitrogen, oxygen, argon and carbon dioxide. It is the right solution if your supply needs range from 1000m3 per month to 10,000m3 per month from gas delivery to on-site storage tanks.
Portable microbulk tank system will increase the transportation efficiency, reduce the cost for both the workers and also the lorry tankers.
ASME standard 5000L-25bar | PCT5000HP | |
MAWP | Mpa(psi) | 2.5(362) |
Max. Pre-set Operating Press | Mpa(psi) | 2.0(290) |
Gross Volume | L(gal) | 5168(1365) |
Net Volume | L(gal) | 4755(1256) |
NER(Nitrogen) | %/Day | 0.6 |
Tare Weight | kg(lbs) | 3000(6614) |
Gaseous Volume(Oxygen) | Nmˆ3(SCF) | 3796(134056) |
Gaseous Volume(Nitrogen) | Nmˆ3(SCF) | 3057(107963) |
Gaseous Volume(Argon) | Nmˆ3(SCF) | 3713(131134) |
Pallet Width "L" | mm(inch) | 3500(137.80) |
Pallet Length "W" | mm(inch) | 2200(86.61) |
Tank Diameter "D" | mm(inch) | 1910(75.2) |
Overall Height "H" | mm(inch) | 2300(90.55) |
Material: | Inner vessel: stainless steel | Outer vessel: stainless steel |
Victank microbulk tanks meet the most stringent international standard. With strict management and test procedure, Victank microbulk tanks enjoy high performance and reliable quality.
Full sets of test report are provided along with microbulk tanks.
Third party test reports are available upon request.
More details about reports and certificates, just contact Victank.
Victank Microbulk tanks always maintain a qualified vacuum and heat preservation performance. We give warranty of 7 years, which is the best and only in the world!
Free training on installation, operation and maintenance.
Life-long technical assistance online.
1unit shipped by 1x20GP container.
3units shipped by 1x40GP container.
Our business has been focusing on brand strategy. Customers' pleasure is our best advertising. We also offer OEM company for Lab 35mpa vertical gas tank in bhutan - Victank, The product will supply to all over the world, such as: San Diego, St. Petersburg, Wellington, Sudan, If you need to have any of our merchandise, or have other items to be produced, make sure you send us your inquiries, samples or in depth drawings. Meanwhile, aiming to develop into an international enterprise group, we look forward to receiving offers for joint ventures and other cooperative projects.
