Our objective is to present premium quality products at aggressive prices, and top-notch services to buyers around the world. We have been ISO9001, CE, and GS certified and strictly adhere to their excellent specifications for Customer pleasure is our main purpose. We welcome you to definitely build business relation with us. For further more information, you should never wait to contact with us.
On-site microbulk storage from VICTANK helps you maximize safety, quality and efficiency in your operations:
• Mode change – no more swapping full-for-empty cylinder handling
• Dedicated cylinder set up for your application
• Product Range from high pressure gas to low pressure liquid delivery
• Built around application unlike high pressure bottle or liquid cylinder
• Ideal for liquid withdrawal
• Right sized for 1 fill per week or 1 fill per month simplifying inventory management
• With right sizing no need for excess cylinder inventory (leads to vent loss)
• Proactive delivery of consistent high purity liquid to eliminate potential contamination
• “Universal” fill system is compatible with all microbulk and bulk delivery transports
Horizontal microbulk tank is suitable for general container loading and also for where the installation space limited by the height.
ASME standard 5000L-16bar | MBH5000MP | |
MAWP | Mpa(psi) | 1.6(230) |
Max. Pre-set Operating Press | Mpa(psi) | 1.0(150) |
Gross Volume | L(gal) | 5031(1329) |
Net Volume | L(gal) | 4779(1263) |
NER(Nitrogen) | %/Day | 0.6 |
Gaseous Volume(Oxygen) | Nmˆ3(SCF) | 3816(134758) |
Gaseous Volume(Nitrogen) | Nmˆ3(SCF) | 3073(108529) |
Gaseous Volume(Argon) | Nmˆ3(SCF) | 3733(131821) |
Gas delivery rate | Nmˆ3/H(SCFH) | 100(3532) |
Pallet Width "A" | mm(inch) | 3150(124.01) |
Pallet Length "B" | mm(inch) | 1400(55.12) |
Tank Diameter "D" | mm(inch) | 1910(75.2) |
Overall Height "H" | mm(inch) | 2150(84.64) |
Width w/piping "w" | mm(inch) | 2230(87.8) |
Material: | Inner vessel: stainless steel | Outer vessel: stainless steel |
Victank microbulk tanks meet the most stringent international standard. With strict management and test procedure, Victank microbulk tanks enjoy high performance and reliable quality.
Full sets of test report are provided along with microbulk tanks.
Third party test reports are available upon request.
More details about reports and certificates, just contact Victank.
Victank Microbulk tanks always maintain a qualified vacuum and heat preservation performance. We give warranty of 7 years, which is the best and only in the world!
Free training on installation, operation and maintenance.
Life-long technical assistance online.
1units shipped by 1x20GP container.
3units shipped by 1x40GP container.
Now we have highly developed devices. Our items are exported towards the USA, the UK and so on, enjoying a great popularity among the customers for Food 5m3 microbulk tank sizes in guyana - Victank, The product will supply to all over the world, such as: Oslo, Bahamas, Riyadh, Mauritania, If any product meed your demand, please feel free to contact us. We're sure your any inquiry or requirement will get prompt attention, high-quality products, preferential prices and cheap freight. Sincerely welcome friends all over the world to call or come to visit, to discuss cooperation for a better future!
