abide by the contract", conforms into the market requirement, joins in the market competition by its good quality also as provides a lot more comprehensive and great company for purchasers to let them turn into huge winner. The pursue from the firm, would be the clients' gratification for We are sincerely looking forward to cooperate with customers all over the world. We believe we can satisfy you. We also warmly welcome customers to visit our company and purchase our products.
On-site microbulk storage from VICTANK helps you maximize safety, quality and efficiency in your operations:
• Mode change – no more swapping full-for-empty cylinder handling
• Dedicated cylinder set up for your application
• Product Range from high pressure gas to low pressure liquid delivery
• Built around application unlike high pressure bottle or liquid cylinder
• Ideal for liquid withdrawal
• Right sized for 1 fill per week or 1 fill per month simplifying inventory management
• With right sizing no need for excess cylinder inventory (leads to vent loss)
• Proactive delivery of consistent high purity liquid to eliminate potential contamination
• “Universal” fill system is compatible with all microbulk and bulk delivery transports
Horizontal microbulk tank is suitable for general container loading and also for where the installation space limited by the height.
ASME standard 5000L-16bar | MBH5000MP | |
MAWP | Mpa(psi) | 1.6(230) |
Max. Pre-set Operating Press | Mpa(psi) | 1.0(150) |
Gross Volume | L(gal) | 5031(1329) |
Net Volume | L(gal) | 4779(1263) |
NER(Nitrogen) | %/Day | 0.6 |
Gaseous Volume(Oxygen) | Nmˆ3(SCF) | 3816(134758) |
Gaseous Volume(Nitrogen) | Nmˆ3(SCF) | 3073(108529) |
Gaseous Volume(Argon) | Nmˆ3(SCF) | 3733(131821) |
Gas delivery rate | Nmˆ3/H(SCFH) | 100(3532) |
Pallet Width "A" | mm(inch) | 3150(124.01) |
Pallet Length "B" | mm(inch) | 1400(55.12) |
Tank Diameter "D" | mm(inch) | 1910(75.2) |
Overall Height "H" | mm(inch) | 2150(84.64) |
Width w/piping "w" | mm(inch) | 2230(87.8) |
Material: | Inner vessel: stainless steel | Outer vessel: stainless steel |
Victank microbulk tanks meet the most stringent international standard. With strict management and test procedure, Victank microbulk tanks enjoy high performance and reliable quality.
Full sets of test report are provided along with microbulk tanks.
Third party test reports are available upon request.
More details about reports and certificates, just contact Victank.
Victank Microbulk tanks always maintain a qualified vacuum and heat preservation performance. We give warranty of 7 years, which is the best and only in the world!
Free training on installation, operation and maintenance.
Life-long technical assistance online.
1units shipped by 1x20GP container.
3units shipped by 1x40GP container.
Reliable good quality and very good credit standing are our principles, which will help us at a top-ranking position. Adhering to your tenet of "quality 1st, purchaser supreme" for 5m3 o2 argon tank in moldova - Victank, The product will supply to all over the world, such as: Swaziland, Cambodia, Cannes, Southampton, Our company insists on the purpose of "takes service priority for standard, quality guarantee for the brand, do business in good faith, to provide professional, rapid, accurate and timely service for you". We welcome old and new customers to negotiate with us. We will serve you with all sincerity!
