Microbulk is used in a wide variety of applications. When you have a storage tank on-site, The truck with the portable microbulk tank pulls up, hooks into the fill connection, and using metered delivery refills your tank.
It is an economic gas transportation for the customers who requires 1000-10000Liters gas,
ASME standard 5000L-16bar | PCT5000MP | |
MAWP | Mpa(psi) | 1.6(230) |
Max. Pre-set Operating Press | Mpa(psi) | 1.0(150) |
Gross Volume | L(gal) | 5168(1365) |
Net Volume | L(gal) | 4755(1256) |
NER(Nitrogen) | %/Day | 0.6 |
Tare Weight | kg(lbs) | 2600(5732) |
Gaseous Volume(Oxygen) | Nmˆ3(SCF) | 3920(138427) |
Gaseous Volume(Nitrogen) | Nmˆ3(SCF) | 3157(111484) |
Gaseous Volume(Argon) | Nmˆ3(SCF) | 3834(135411) |
Pallet Width "L" | mm(inch) | 3500(137.80) |
Pallet Length "W" | mm(inch) | 2200(86.61) |
Tank Diameter "D" | mm(inch) | 1910(75.2) |
Overall Height "H" | mm(inch) | 2300(90.55) |
Material: | Inner vessel: stainless steel | Outer vessel: stainless steel |
Victank microbulk tanks meet the most stringent international standard. With strict management and test procedure, Victank microbulk tanks enjoy high performance and reliable quality.
Full sets of test report are provided along with microbulk tanks.
Third party test reports are available upon request.
More details about reports and certificates, just contact Victank.
Victank Microbulk tanks always maintain a qualified vacuum and heat preservation performance. We give warranty of 7 years, which is the best and only in the world!
Free training on installation, operation and maintenance.
Life-long technical assistance online.
1unit shipped by 1x20GP container.
3units shipped by 1x40GP container.
