Victank microbulk tanks offer a better solution of end-to-end liquid gas delivery, An ideal solution for medium size customers in industries, medical, cutting, lab and etc.
Various capacity optional 1000L 2000L,3000L,5000L; Working pressure 16bar, 24bar,35bar.
Innovation liquid nitrogen tank or liquid nitrogen container—Microbulk, helps you keep continued and steady working condition for laser cutting! Microbulk tank is popular been used as industrial liquid gas tank.
How we make the Microbulk nitrogen storage tank to be the best solution for laser cutting? This liquid nitrogen tank features: Built on skid which makes it easier for installation; Special designed PBU allows the tank pressure increase to 30bar very quickly. The liquid nitrogen container suitable for whole laser cutting demands; Fast pressure building-up; Large Nitrogen output capacity to meet the high power laser machine requirement.
Microbulk nitrogen tanks for sale, customized liquid gas tank is available, and you could also equip a spare Microbulk to keep uninterrupted gas delivery even when in filling.
ASME standard 3000L-16bar | MB3000MP | |
MAWP | Mpa(psi) | 1.6(230) |
Max. Pre-set Operating Press | Mpa(psi) | 1.0(150) |
Gross Volume | L(gal) | 3031(801) |
Net Volume | L(gal) | 2879(761) |
NER(Nitrogen) | %/Day | 0.5 |
Tare Weight | kg(lbs) | 1750(3858) |
Gaseous Volume(Oxygen) | Nmˆ3(SCF) | 2299(81187) |
Gaseous Volume(Nitrogen) | Nmˆ3(SCF) | 1851(65385) |
Gaseous Volume(Argon) | Nmˆ3(SCF) | 2249(79417) |
Gas delivery rate | Nmˆ3/H(SCFH) | 75(2649) |
Pallet Width "A" | mm(inch) | 1700(66.92) |
Pallet Length "B" | mm(inch) | 1700(66.92) |
Tank Diameter "D" | mm(inch) | 1508(59.37) |
Overall Height "H" | mm(inch) | 3160(124.41) |
Material: | Inner vessel: stainless steel | Outer vessel: stainless steel |
Victank microbulk tanks meet the most stringent international standard. With strict management and test procedure, Victank microbulk tanks enjoy high performance and reliable quality.
Full sets of test report are provided along with microbulk tanks.
Third party test reports are available upon request.
More details about reports and certificates, just contact Victank.
Victank Microbulk tanks always maintain a qualified vacuum and heat preservation performance. We give warranty of 7 years, which is the best and only in the world!
Free training on installation, operation and maintenance.
Life-long technical assistance online.
4units 1m3 microbulk tank shipped by one 20FT container.
3units 2m3 microbulk tank shipped by one 20OT container. (open top container)
3units 3m3 microbulk tank shipped by one 20OT container. (open top container)
2units 5m3 microbulk tank shipped by one 20OT container. (open top container)
