Our microbulk smart tanker assures you of fast discharging of liquid gases, and gives you an efficient microbulk gas delivery solution.
You may have met the troublesome problem about the common lorry tanker: the discharging speed is unbearably low due to the pressure drop in tanker. Even the capacity of PB vaporizer increased, the discharging speed remains low when there is few liquid in tanker.
To solve this problem, we adopt the innovative PB tank technology and ensure a stable higher pressure when discharging. Our microbulk smart tanker can reach the discharging speed as fast as the tanker with pump. We can also add auto-operational devices as optional.
Victank microbulk smart tanker: Small, Speedy, Smart!
NO | NAME | PARAMETERS | |||
1 | Model No. | LT4.2-1.8 | LT5.2-1.8 | LT7.2-1.8 | LT9.2-1.8 |
2 | Gross Volume | 4189 L | 5194 L | 7205 L | 9215 L |
3 | Net Volume | 3980 L | 4778 L | 6845 L | 8754 L |
4 | PB Tank Net Volume | 364 L | 364 L | 364 L | 364 L |
5 | Max Working Pressure | 1.8 MPa | 1.8 MPa | 1.8 MPa | 1.8 MPa |
6 | PB Tank MAWP | 2.4 MPa | 2.4 MPa | 2.4 MPa | 2.4 MPa |
7 | Max Dispensing Pressure | 1.65 MPa | 1.65 MPa | 1.65 MPa | 1.65 MPa |
8 | Max Dispensing Rate | 379 LPM | 379 LPM | 379 LPM | 379 LPM |
9 | Loading Medium | LIN, LOX, LAR | |||
10 | Design Code | ASME | |||
11 | Main Material | Inner Vessel | SA-240M 304 | ||
Outer Vessel | Q235B | ||||
12 | Design Temperature | ‐196/+50℃ | |||
13 | Isolating Type | High vacuum multi-layer | |||
Victank microbulk lorry tanker meet the most stringent international standard. With strict management and test procedure, Victank microbulk lorry tankers enjoy high performance and reliable quality.
Full sets of test report are provided along with microbulk delivery system cryogenic lorry tanker.
Third party test reports are available upon request.
Victank Microbulk tankers always maintain a qualified vacuum and heat preservation performance. Free training on installation, operation and maintenance.
Life-long technical assistance online.
