35bar ar horizontal gas tank in dominica - Victank
Portable Microbulk Tank for Transportation PCT2000HP
Inquire

"Quality to start with, Honesty as base, Sincere company and mutual profit" is our idea, as a way to build constantly and pursue the excellence for Our concept would be to assist presenting the confidence of each prospective buyers while using the offering of our most honest service, as well as right merchandise.

Description

Microbulk enable small and medium volume users to enjoy the benefits of on-site gas delivery. Microbulk Transportation and Storage Systems provide reliable, efficient and economical solutions for liquid nitrogen, oxygen, argon, CO2, N2O, and LNG.

Designed to replace high pressure gas cylinders, VICTANK eliminates:

•      waste and expense of full for empty gas cylinders

•      cylinder change-overs

•      residual gas losses

•      lost or damaged cylinders

•      cylinder inventory management

•      manual handling injuries

microbulk tank, liquid oxygen tank, lox tank, cryogenic tank, Liquid nitrogen tank, LIN, LAR, LCO2, LNG, liquid argon, liquid gas tank, medical

Technical Datasheet

ASME standard 2000L-25bar

PCT2000HP

MAWP

Mpa(psi)

2.5(362)

Max. Pre-set Operating Press

Mpa(psi)

2.0(290)

Gross Volume

L(gal)

3031(801)

Net Volume

L(gal)

2789(737)

NER(Nitrogen)

%/Day

0.8

Tare Weight

kg(lbs)

1515(3340)

Gaseous Volume(Oxygen)

Nmˆ3(SCF)

1548(54655)

Gaseous Volume(Nitrogen)

Nmˆ3(SCF)

1246(44017)

Gaseous Volume(Argon)

Nmˆ3(SCF)

1514(53464)

Gas delivery rate

Nmˆ3/H(SCFH)


Pallet Width "L"

mm(inch)

3300(129.92)

Pallet Length "W"

mm(inch)

1600(62.99)

Tank Diameter "D"

mm(inch)

1308(51.5)

Overall Height "H"

mm(inch)

1700(66.93)

Material:

Inner  vessel: stainless steel

Outer vessel: stainless steel


Reports & Certificate

Victank microbulk tanks meet the most stringent international standard. With strict management and test procedure, Victank microbulk tanks enjoy high performance and reliable quality.

Full sets of test report are provided along with microbulk tanks.

Third party test reports are available upon request.

More details about reports and certificates, just contact Victank.

Warranty

Victank Microbulk tanks always maintain a qualified vacuum and heat preservation performance. We give warranty of 7 years, which is the best and only in the world!

Free training on installation, operation and maintenance.

Life-long technical assistance online.


Packaging & Shipping


1unit shipped by 1x20GP container.

3units shipped by 1x40GP container.
