Home >> 3000l argon microbulk storage in ecuador - Victank
//a0.leadongcdn.cn/cloud/mjBpoKriRlkSoiqqmrjrj/microbulk-tank-oxygen-tank-liquid-oxygen-liquid-nitrogen-liquid-argon-LCO2.jpg
3000l argon microbulk storage in ecuador - Victank
Microbulk Tank Horizontal MBH5000MP
Inquire

Sticking to your belief of "Creating solutions of high quality and generating buddies with people from all around the world", we always put the fascination of customers to start with for Our company is dedicated to providing customers with high and stable quality products at competitive price, making every customer satisfied with our products and services.

Description

On-site microbulk storage from VICTANK helps you maximize safety, quality and efficiency in your operations:

• Mode change – no more swapping full-for-empty cylinder handling

• Dedicated cylinder set up for your application

• Product Range from high pressure gas to low pressure liquid delivery

• Built around application unlike high pressure bottle or liquid cylinder

• Ideal for liquid withdrawal

• Right sized for 1 fill per week or 1 fill per month simplifying inventory management

• With right sizing no need for excess cylinder inventory (leads to vent loss)

• Proactive delivery of consistent high purity liquid to eliminate potential contamination

• “Universal” fill system is compatible with all microbulk and bulk delivery transports

Horizontal microbulk tank is suitable for general container loading and also for where the installation space limited by the height.


microbulk tank, liquid oxygen tank, lox tank, cryogenic tank, Liquid nitrogen tank, LIN, LAR, LCO2, LNG, liquid argon, liquid gas tank, medical

Technical Datasheet

ASME standard 5000L-16bar

MBH5000MP

MAWP

Mpa(psi)

1.6(230)

Max. Pre-set Operating Press

Mpa(psi)

1.0(150)

Gross Volume

L(gal)

5031(1329)

Net Volume

L(gal)

4779(1263)

NER(Nitrogen)

%/Day

0.6

Gaseous Volume(Oxygen)

Nmˆ3(SCF)

3816(134758)

Gaseous Volume(Nitrogen)

Nmˆ3(SCF)

3073(108529)

Gaseous Volume(Argon)

Nmˆ3(SCF)

3733(131821)

Gas delivery rate

Nmˆ3/H(SCFH)

100(3532)

Pallet Width "A"

mm(inch)

3150(124.01)

Pallet Length "B"

mm(inch)

1400(55.12)

Tank Diameter "D"

mm(inch)

1910(75.2)

Overall Height "H"

mm(inch)

2150(84.64)

Width w/piping "w"

mm(inch)

2230(87.8)

Material:

Inner vessel: stainless steel

Outer vessel: stainless steel


Reports & Certificate

Victank microbulk tanks meet the most stringent international standard. With strict management and test procedure, Victank microbulk tanks enjoy high performance and reliable quality.

Full sets of test report are provided along with microbulk tanks.

Third party test reports are available upon request.

More details about reports and certificates, just contact Victank.

Warranty

Victank Microbulk tanks always maintain a qualified vacuum and heat preservation performance. We give warranty of 7 years, which is the best and only in the world!

Free training on installation, operation and maintenance.

Life-long technical assistance online.


Packaging & Shipping


1units shipped by 1x20GP container.

3units shipped by 1x40GP container.


Are you interested in saving some money on importing any of the following? 3000l argon microbulk storage in ecuador - Victank, The product will supply to all over the world, such as: Malawi, kazan, Korea, Bahamas, Our company has abundant strength and possesses a steady and perfect sales network system. We wish we could establish sound business relationships with all customers from at home and abroad on the basis of mutual benefits.
