25mpa lo2 microbulk systems in costa rica - Victank
Microbulk Tank MB1000MP
Inquire

Sorry to trouble you again! Please find my mail below. Welcome to visit us at any time for business relationship established.

Description

Microbulk, modern conception of gas supplied on-site

Microbulk is a modern concept where your gas is supplied by filling on-site vs. the traditional method by handling numbers of empty cylinders and dewars. Microbulk enjoys outstanding features mean exceptional performance.

Microbulk systems are available for oxygen, nitrogen, argon, carbon dioxide, nitrous oxide(N2O), LNG. Microbulk tank is widely used in industrial, medical, welding and cutting field, etc.

microbulk tank, liquid oxygen tank, lox tank, cryogenic tank, Liquid nitrogen tank, LIN, LAR, LCO2, LNG, liquid argon, medical, liquid gas tank (2)

Technical Datasheet

ASME standard 1000L-16bar

MB1000MP

MAWP

Mpa(psi)

1.6(230)

Max. Pre-set Operating Press

Mpa(psi)

1.0(150)

Gross Volume

L(gal)

1040(275)

Net Volume

L(gal)

988(261)

NER(Nitrogen)

%/Day

0.7

Tare Weight

kg(lbs)

730(1609)

Gaseous Volume(Oxygen)

Nmˆ3(SCF)

789(27857)

Gaseous Volume(Nitrogen)

Nmˆ3(SCF)

635(22435)

Gaseous Volume(Argon)

Nmˆ3(SCF)

772(27250)

Gas delivery rate

Nmˆ3/H(SCFH)

40(1413)

Pallet Width "A"

mm(inch)

1250(49.21)

Pallet Length "B"

mm(inch)

1250(49.21)

Tank Diameter "D"

mm(inch)

1108(43.62)

Overall Height "H"

mm(inch)

2245(88.38)

Material:

Inner vessel: stainless steel

Outer vessel: stainless steel



Reports & Certificate

Victank microbulk tanks meet the most stringent international standard. With strict management and test procedure, Victank microbulk tanks enjoy high performance and reliable quality.

Full sets of test report are provided along with microbulk tanks.

Third party test reports are available upon request.

More details about reports and certificates, just contact Victank.

Warranty

Victank Microbulk tanks always maintain a qualified vacuum and heat preservation performance. We give warranty of 7 years, which is the best and only in the world!

Free training on installation, operation and maintenance.

Life-long technical assistance online.


Packaging & Shipping

4units 1m3 microbulk tank shipped by one 20FT container.

3units 2m3 microbulk tank shipped by one 20OT container. (open top container)

3units 3m3 microbulk tank shipped by one 20OT container. (open top container)

2units 5m3 microbulk tank shipped by one 20OT container. (open top container)

microbulk tank, liquid oxygen tank, lox tank, cryogenic tank, Liquid nitrogen tank, LIN, LAR, LCO2, LNG, liquid argon, medical, liquid gas tank (3)

Together with the "Client-Oriented" enterprise philosophy, a arduous good quality control technique, sophisticated producing equipment and a sturdy R 25mpa lo2 microbulk systems in costa rica - Victank, The product will supply to all over the world, such as: Provence, Costa rica, Botswana, Manila, Satisfaction and good credit to every customer is our priority. We focus on every detail of order processing for customers till they have received safe and sound solutions with good logistics service and economical cost. Depending on this, our solutions are sold very well in the countries in Africa, the Mid-East and Southeast Asia.
