25mpa lar horizontal gas tank in germany - Victank
Portable Microbulk Tank for Transportation PCT2000MP
Inquire

We now have our own gross sales team, style and design workforce, technical crew, QC workforce and package group. We now have strict quality manage procedures for each system. Also, all of our workers are experienced in printing industry for We always welcome new and old customers presents us with valuable advice and proposals for cooperation, let us grow and develop together, and to contribute to our community and staff!

Description

Microbulk is a Complete gas supply and management solution that enables users of all sizes to enjoy the cost and efficiency benefits of switching to liquid gas from high pressure gas cylinders.

Economic gas transportation for the customers who requires 1000-10000Liters gas, increasing the transportation efficiency, reducing the cost for both the workers and also the lorry tankers.


microbulk tank, liquid oxygen tank, lox tank, cryogenic tank, Liquid nitrogen tank, LIN, LAR, LCO2, LNG, liquid argon, liquid gas tank, medical

Technical Datasheet

ASME standard 2000L-16bar

PCT2000MP

MAWP

Mpa(psi)

1.6(230)

Max. Pre-set Operating Press

Mpa(psi)

1.0(150)

Gross Volume

L(gal)

2107(557)

Net Volume

L(gal)

1938(512)

NER(Nitrogen)

%/Day

0.8

Tare Weight

kg(lbs)

1350(2976)

Gaseous Volume(Oxygen)

Nmˆ3(SCF)

1548(54655)

Gaseous Volume(Nitrogen)

Nmˆ3(SCF)

1246(44017)

Gaseous Volume(Argon)

Nmˆ3(SCF)

1514(53464)

Pallet Width "L"

mm(inch)

3300(129.92)

Pallet Length "W"

mm(inch)

1600(62.99)

Tank Diameter "D"

mm(inch)

1308(51.5)

Overall Height "H"

mm(inch)

1700(66.93)

Material:

Inner vessel: stainless steel

Outer vessel: stainless steel


Reports & Certificate

Victank microbulk tanks meet the most stringent international standard. With strict management and test procedure, Victank microbulk tanks enjoy high performance and reliable quality.

Full sets of test report are provided along with microbulk tanks.

Third party test reports are available upon request.

More details about reports and certificates, just contact Victank.

Warranty

Victank Microbulk tanks always maintain a qualified vacuum and heat preservation performance. We give warranty of 7 years, which is the best and only in the world!

Free training on installation, operation and maintenance.

Life-long technical assistance online.


Packaging & Shipping


1unit shipped by 1x20GP container.

3units shipped by 1x40GP container.


We are a professional supplier, with our own factory and R&D department. We have strong production capacity and professional design team to provide the best service for our customers. 25mpa lar horizontal gas tank in germany - Victank, The product will supply to all over the world, such as: Myanmar, Johannesburg, Zurich, Hyderabad, With all these supports, we can serve every customer with quality product and timely shipping with highly responsibility. Being a young growing company, we might not the best, but we are trying our best to be your good partner.
