Adhering to your principle of "quality, assistance, performance and growth", we have now gained trusts and praises from domestic and international customer for We fully welcome shoppers from all around the world to ascertain stable and mutually effective enterprise interactions, to have a dazzling long run jointly.
The microbulk supply platform is the right solution if your supply needs range from 500m3 per month to 100,000m3 per month. Microbulk storage system tank capacities range from 1000 to 5,000 liters and are able to accommodate pressure requirements of up to 500 psi. We supply storage tanks in a range of sizes and can easily change on-site installations to evolve with your growing volume requirements.
ASME standard 3000L-35bar | MBH3000VHP | |
MAWP | Mpa(psi) | 3.5(500) |
Max. Pre-set Operating Press | Mpa(psi) | 3.1(450) |
Gross Volume | L(gal) | 3031(801) |
Net Volume | L(gal) | 2789(737) |
NER(Nitrogen) | %/Day | 0.7 |
Gaseous Volume(Oxygen) | Nmˆ3(SCF) | 2226(78623) |
Gaseous Volume(Nitrogen) | Nmˆ3(SCF) | 1793(63320) |
Gaseous Volume(Argon) | Nmˆ3(SCF) | 2178(76910) |
Gas delivery rate | Nmˆ3/H(SCFH) | 75(2649) |
Pallet Width "A" | mm(inch) | 3200(125.98) |
Pallet Length "B" | mm(inch) | 1100(43.3) |
Tank Diameter "D" | mm(inch) | 1508(59.37) |
Overall Height "H" | mm(inch) | 1880(74.01) |
Width w/piping "w" | mm(inch) | 1826(71.89) |
Material: | Inner vessel: stainless steel | Outer vessel: stainless steel |
Victank microbulk tanks meet the most stringent international standard. With strict management and test procedure, Victank microbulk tanks enjoy high performance and reliable quality.
Full sets of test report are provided along with microbulk tanks.
Third party test reports are available upon request.
More details about reports and certificates, just contact Victank.
Victank Microbulk tanks always maintain a qualified vacuum and heat preservation performance. We give warranty of 7 years, which is the best and only in the world!
Free training on installation, operation and maintenance.
Life-long technical assistance online.
1units shipped by 1x20GP container.
3units shipped by 1x40GP container.
"Sincerity, Innovation, Rigorousness, and Efficiency" could be the persistent conception of our enterprise to the long-term to produce together with clients for mutual reciprocity and mutual profit for 25mpa ar horizontal gas tank in slovenia - Victank, The product will supply to all over the world, such as: Leicester, Riyadh, Cairo, Palestine, In order to meet our market demands, we have paied more attention to the quality of our products and services. Now we can meet customers' special requirements for special designs. We persistently develop our enterprise spirit "quality lives the enterprise, credit assures cooperation and keep the motto in our minds: customers first.
