MicroBulk is a cost-effective gas management solution that provides the efficiencies of bulk delivery to smaller volume users of nitrogen, oxygen, argon and carbon dioxide. It is the right solution if your supply needs range from 1000m3 per month to 10,000m3 per month from gas delivery to on-site storage tanks.
Portable microbulk tank system will increase the transportation efficiency, reduce the cost for both the workers and also the lorry tankers.
ASME standard 5000L-25bar | PCT5000HP | |
MAWP | Mpa(psi) | 2.5(362) |
Max. Pre-set Operating Press | Mpa(psi) | 2.0(290) |
Gross Volume | L(gal) | 5168(1365) |
Net Volume | L(gal) | 4755(1256) |
NER(Nitrogen) | %/Day | 0.6 |
Tare Weight | kg(lbs) | 3000(6614) |
Gaseous Volume(Oxygen) | Nmˆ3(SCF) | 3796(134056) |
Gaseous Volume(Nitrogen) | Nmˆ3(SCF) | 3057(107963) |
Gaseous Volume(Argon) | Nmˆ3(SCF) | 3713(131134) |
Pallet Width "L" | mm(inch) | 3500(137.80) |
Pallet Length "W" | mm(inch) | 2200(86.61) |
Tank Diameter "D" | mm(inch) | 1910(75.2) |
Overall Height "H" | mm(inch) | 2300(90.55) |
Material: | Inner vessel: stainless steel | Outer vessel: stainless steel |
Victank microbulk tanks meet the most stringent international standard. With strict management and test procedure, Victank microbulk tanks enjoy high performance and reliable quality.
Full sets of test report are provided along with microbulk tanks.
Third party test reports are available upon request.
More details about reports and certificates, just contact Victank.
Victank Microbulk tanks always maintain a qualified vacuum and heat preservation performance. We give warranty of 7 years, which is the best and only in the world!
Free training on installation, operation and maintenance.
Life-long technical assistance online.
1unit shipped by 1x20GP container.
3units shipped by 1x40GP container.
