16mpa lo2 argon tank in namibia - Victank
Microbulk Tank Horizontal MBH5000MP
Inquire

To meet the customers' over-expected gratification , we have our robust crew to offer our best over-all support which includes marketing, income, coming up with, production, excellent managing, packing, warehousing and logistics for We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success!

Description

On-site microbulk storage from VICTANK helps you maximize safety, quality and efficiency in your operations:

• Mode change – no more swapping full-for-empty cylinder handling

• Dedicated cylinder set up for your application

• Product Range from high pressure gas to low pressure liquid delivery

• Built around application unlike high pressure bottle or liquid cylinder

• Ideal for liquid withdrawal

• Right sized for 1 fill per week or 1 fill per month simplifying inventory management

• With right sizing no need for excess cylinder inventory (leads to vent loss)

• Proactive delivery of consistent high purity liquid to eliminate potential contamination

• “Universal” fill system is compatible with all microbulk and bulk delivery transports

Horizontal microbulk tank is suitable for general container loading and also for where the installation space limited by the height.


microbulk tank, liquid oxygen tank, lox tank, cryogenic tank, Liquid nitrogen tank, LIN, LAR, LCO2, LNG, liquid argon, liquid gas tank, medical

Technical Datasheet

ASME standard 5000L-16bar

MBH5000MP

MAWP

Mpa(psi)

1.6(230)

Max. Pre-set Operating Press

Mpa(psi)

1.0(150)

Gross Volume

L(gal)

5031(1329)

Net Volume

L(gal)

4779(1263)

NER(Nitrogen)

%/Day

0.6

Gaseous Volume(Oxygen)

Nmˆ3(SCF)

3816(134758)

Gaseous Volume(Nitrogen)

Nmˆ3(SCF)

3073(108529)

Gaseous Volume(Argon)

Nmˆ3(SCF)

3733(131821)

Gas delivery rate

Nmˆ3/H(SCFH)

100(3532)

Pallet Width "A"

mm(inch)

3150(124.01)

Pallet Length "B"

mm(inch)

1400(55.12)

Tank Diameter "D"

mm(inch)

1910(75.2)

Overall Height "H"

mm(inch)

2150(84.64)

Width w/piping "w"

mm(inch)

2230(87.8)

Material:

Inner vessel: stainless steel

Outer vessel: stainless steel


Reports & Certificate

Victank microbulk tanks meet the most stringent international standard. With strict management and test procedure, Victank microbulk tanks enjoy high performance and reliable quality.

Full sets of test report are provided along with microbulk tanks.

Third party test reports are available upon request.

More details about reports and certificates, just contact Victank.

Warranty

Victank Microbulk tanks always maintain a qualified vacuum and heat preservation performance. We give warranty of 7 years, which is the best and only in the world!

Free training on installation, operation and maintenance.

Life-long technical assistance online.


Packaging & Shipping


1units shipped by 1x20GP container.

3units shipped by 1x40GP container.


Our intention should be to fulfill our consumers by offering golden provider, superior price and superior quality for 16mpa lo2 argon tank in namibia - Victank, The product will supply to all over the world, such as: Dominica, Lahore, France, Bangkok, Make the women more attractive is our sales philosophy. "Being customers' trusted and preferred brand supplier" is the goal of our company. We are strict with every part of our work. We sincerely welcome friends to negotiate business and start cooperation. We hope to join hands with friends in different industries to create a brilliant future.
