16mpa ar liquid argon tank in mongolia - Victank
Portable Microbulk Tank for Transportation PCT2000HP
Inquire

With this motto in mind, we've come to be one of quite possibly the most technologically innovative, cost-efficient, and price-competitive manufacturers for If you are interested within our products and solutions, you should come to feel absolutely free to ship us your inquiry. We sincerely hope to ascertain win-win company relationships with you.

Description

Microbulk enable small and medium volume users to enjoy the benefits of on-site gas delivery. Microbulk Transportation and Storage Systems provide reliable, efficient and economical solutions for liquid nitrogen, oxygen, argon, CO2, N2O, and LNG.

Designed to replace high pressure gas cylinders, VICTANK eliminates:

•      waste and expense of full for empty gas cylinders

•      cylinder change-overs

•      residual gas losses

•      lost or damaged cylinders

•      cylinder inventory management

•      manual handling injuries

microbulk tank, liquid oxygen tank, lox tank, cryogenic tank, Liquid nitrogen tank, LIN, LAR, LCO2, LNG, liquid argon, liquid gas tank, medical

Technical Datasheet

ASME standard 2000L-25bar

PCT2000HP

MAWP

Mpa(psi)

2.5(362)

Max. Pre-set Operating Press

Mpa(psi)

2.0(290)

Gross Volume

L(gal)

3031(801)

Net Volume

L(gal)

2789(737)

NER(Nitrogen)

%/Day

0.8

Tare Weight

kg(lbs)

1515(3340)

Gaseous Volume(Oxygen)

Nmˆ3(SCF)

1548(54655)

Gaseous Volume(Nitrogen)

Nmˆ3(SCF)

1246(44017)

Gaseous Volume(Argon)

Nmˆ3(SCF)

1514(53464)

Gas delivery rate

Nmˆ3/H(SCFH)


Pallet Width "L"

mm(inch)

3300(129.92)

Pallet Length "W"

mm(inch)

1600(62.99)

Tank Diameter "D"

mm(inch)

1308(51.5)

Overall Height "H"

mm(inch)

1700(66.93)

Material:

Inner  vessel: stainless steel

Outer vessel: stainless steel


Reports & Certificate

Victank microbulk tanks meet the most stringent international standard. With strict management and test procedure, Victank microbulk tanks enjoy high performance and reliable quality.

Full sets of test report are provided along with microbulk tanks.

Third party test reports are available upon request.

More details about reports and certificates, just contact Victank.

Warranty

Victank Microbulk tanks always maintain a qualified vacuum and heat preservation performance. We give warranty of 7 years, which is the best and only in the world!

Free training on installation, operation and maintenance.

Life-long technical assistance online.


Packaging & Shipping


1unit shipped by 1x20GP container.

3units shipped by 1x40GP container.


We can normally fulfill our respected consumers with our great excellent, great value and good provider due to we're much more specialist and extra hard-working and do it in cost-effective way for 16mpa ar liquid argon tank in mongolia - Victank, The product will supply to all over the world, such as: United Arab emirates, venezuela, Norwegian, Melbourne, If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients around the world in the near future.
